High Power Omniblock® (180 kV @ 13.3 mA) with integrated metal ceramic X-ray tube.
This robust, complete X-Ray generator system is designed withstand up to 20 G (rms)
force in rotating gantry applications for Security, Food Inspection, Medical and Industrial
non-destructive testing applications.
본문
* The Omni 180 kV 13.3 mA is the base building block used to create a high power OEM Omniblock platform specific to customer applications.
* Designed to operated continuously with maximum output power of 2.4 kW at 180 kV and 13.3 mA
* Standard X-Ray nozzles produces Fan Beam Angle XY Plane:100 Degrees and YZ Plane of 10.5 degrees.
* Modified beam angles nozzles can be developed if they are within parameters of the X-Ray Tube
* Protection and Safety circuitry for Over Current, Over Voltage, Arc Detection, X-Ray On, Power Limit Faults and Regulation Faults
